Home > Products > Cutting Machinery > Cutting Robot

Cutting Robot

Product categories of Cutting Robot, we are specialized manufacturers from China, Cutting Robot, Automatic Cutting Robot suppliers/factory, wholesale high-quality products of Cutting Coordinate Linear Robot R & D and manufacturing, we have the perfect after-sales service and technical support. Look forward to your cooperation!

View:

    • Curved plate bevel cutting machine

    Curved plate bevel cutting machine

    • Brand: LongXuan

    • Packaging: Wooden Box or According To Customer Requests

    • Min. Order: 1 Set/Sets

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Curved plate bevel cutting machine Introduction Curved plate bevel cutting machine is suitable for the measurement scribing second precise cutting and variable angle double sided groove cutting of the thick walled pressure vessels of ellipsoidal head plate spherical tank ball and other types Cutting Robot is adapted...

    • Cutting Robot for Curved Plate Bevel

    Cutting Robot for Curved Plate Bevel

    • Brand:  Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Cutting Robot for Curved Plate Bevel Performance characteristics Ensure the arc length precision of each steel plate thus ensuring the interchangeability of steel plate The quality of the cutting surface is high thereby reducing the grinding and welding defects Cutting robot for curved plate bevel can automatically...

    • Magnetic Crawling Cutting Machine

    Magnetic Crawling Cutting Machine

    • Brand:  Longxuan

    • Packaging: According to the Orders

    • Model No.: MCCR-5

    • Place of Origin: China (Mainland)

    • Transportation: Ocean,Land

    Magnetic Crawling Cutting Machine Scope of application Magnetic crawling cutting robot complete all position cutting in wheeled magnetic crawling way It is suitable for the cutting of industrial field such as the cutting of

    • Gantry Cutting Machine for Intersecting Lines

    Gantry Cutting Machine for Intersecting Lines

    • Brand: Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Gantry Cutting Robot for Intersecting Lines Scope of Application This robot can automaticly open holes on cylindrical shell and head through visual localization technology with several axes It can be used to cut variable intersecting lines on cylindrical shell and head in high precision and efficiency especially good...

    • Saddle Welding and Cutting Robot

    Saddle Welding and Cutting Robot

    • Brand: Longxuan

    • Packaging: According to the customers\'orders

    • Min. Order: 1 Set/Sets

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Saddle Welding and Cutting Machine This cutting robot can be applied to various industrial fields such as pressure vessels for the chemical industray station boiler nuclear power equipment food and pharmaceutical equipment ship and ocean engineeing national defense industray and so on It can be applied to saddle...

    • Curved Plate Bevel Cutting Robot

    Curved Plate Bevel Cutting Robot

    • Brand:  Longxuan

    • Packaging: According to the Customers\'Orders

    • Model No.: MPCR-5D6000

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Curved plate bevel cutting robot Scope of application This equipment is suitable for the measurement scribing second precise cutting and variable angle double sided groove cutting of the thick walled pressure vessels of ellipsoidal head plate spherical tank ball and other types It s suitable for quick batch high...

    • Gantry Cutting Robot of Intersecting Lines

    Gantry Cutting Robot of Intersecting Lines

    • Brand:  Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Model No.: PHCR

    • Place of Origin: Hebei, China (Mainland)

    Gantry Cutting Robot of Intersecting Lines Scope of Application This robot can automaticly open holes on cylindrical shell and head through visual localization technology with several axes It can be used to cut variable intersecting lines on cylindrical shell and head in high precision and efficiency especially good...

    • Cutting Robot of Intersecting Lines

    Cutting Robot of Intersecting Lines

    • Brand: Longxuan

    • Packaging: Wooden Box or According To Customer Requests

    • Min. Order: 1 Set/Sets

    • Model No.: MPCR-6D4000

    • Place of Origin: China (Mainland)

    Cutting robot of intersecting lines on cylinder head Scope of application This equipment is suitable for the measurement scribing second precise cutting and variable angle doublesided groove cutting with double welding guns of spherical type elliptic type cone type butterfly type and other types head It s also well...

    • Spiral plate heat exchanger cutting robot

    Spiral plate heat exchanger cutting robot

    • Brand: Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Model No.: SEWR-2500

    • Place of Origin: Hebei, China (Mainland)

    Spiral plate heat exchanger welding robot 1 Scope of application This welding robot is mainly concentrating on the welding of spiral plate heat exchanger with diameter below 2500mm It applies the advanced technology of vision tracking and three axis linkage numerical control system with high precision to complete the...

    • Curve NC Simplified Cutting Robot

    Curve NC Simplified Cutting Robot

    • Brand: Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    GS G10 TT curve nc simplified cutting machine Product details GS G10 TT CNC cylindrical intersection wire cutting machine is a CNC controlled tube cutting machine The cutting robot adopts plasma cutting which is suitable for the cutting of low carbon steel and stainless steel tube workpiece material greatly improving...

    • Gantry Cutting Robot for Intersecting Lines

    Gantry Cutting Robot for Intersecting Lines

    • Brand: Longxuan

    • Packaging: According to the Customers\'Orders

    • Min. Order: 1 Set/Sets

    • Model No.: PHCR

    • Place of Origin: Hebei, China (Mainland)

    Gantry Cutting Robot of Intersecting Lines This robot can automaticly open holes on cylindrical shell and head through visual localization technology with several axes It can be used to cut variable intersecting lines on cylindrical shell and head in highprecision and efficiency especially good at cutting more than...

    • Intersecting Lines Pipe Cutting Robot

    Intersecting Lines Pipe Cutting Robot

    • Brand: Longxuan

    • Packaging: According to the customers\'orders

    • Min. Order: 1 Set/Sets

    • Model No.: FWPC

    • Place of Origin: Hebei, China (Mainland)

    Pipe Intersecting Lines Cutting Robot Scope of application The automatic cutting machine is a formed cutting equipment used for fully automatic incising intersecting lines with slope on pipes and cutting pipe end for example one time molding cutting intersecting lines or opening holes on bearing steel pipes and gas...

    • Pipe Intersecting Line Cutting Robot

    Pipe Intersecting Line Cutting Robot

    • Brand: Longxuan

    • Packaging: According to the customers\'orders

    • Min. Order: 1 Set/Sets

    • Model No.: GD800

    • Place of Origin: Hebei, China (Mainland)

    Pipe Intersecting Line Cutting Robot GD800 Scope of application This Cutting Robot can be applied to various industrial fields such as Ocean engineering Steel structure Chemical pressure container and Bridge etc The Automatic Pipe Cutter can be applied to tube square groove cutting include multi tube space...

    • Square Tube Cutting Robot

    Square Tube Cutting Robot

    • Brand:  Longxuan

    • Packaging: According to the Orders

    • Min. Order: 1 Set/Sets

    • Place of Origin: China (Mainland)

    • Transportation: Ocean,Land

    Square Tube Cutting Robot The scope of application The Cutting Robot can realize the 3D positioning and cutting of the square tube profile which is suitable for the opening and length of the square pipe profile the groove and the intersecting line cutting The Cutting Machine is suitable for steel structure marine...

    • Magnetic Crawling Cutting Robot

    Magnetic Crawling Cutting Robot

    • Brand:  Longxuan

    • Packaging: According to the Orders

    • Model No.: MCCR-5

    • Place of Origin: China (Mainland)

    • Transportation: Ocean,Land

    Magnetic crawling cutting robot Scope of application Magnetic crawling cutting robot complete all position cutting in wheeled magnetic crawling way It is suitable for the cutting of industrial field such as the cutting of ball ellipse plate head plate It can complete the various types of spatial curved bevel cutting...

    • Cutting Robot of Intersecting Lines on Head

    Cutting Robot of Intersecting Lines on Head

    • Brand: Longxuan

    • Packaging: Wooden Box or According To Customer Requests

    • Model No.: MPCR-6D4000

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    Cutting Robot of Intersecting Lines on Head This equipment is suitable for the measurement scribing second precise cutting and variable angle doublesided groove cutting with double welding guns of spherical type elliptic type cone type butterfly type and other types head It s also well used for quick batch high...

    • CNC Pipe Intersecting Line Cutting Machine

    CNC Pipe Intersecting Line Cutting Machine

    • Brand: Longxuan

    • Packaging: According to the customers\'orders

    • Model No.: CPC Series,FWPC Serie

    • Place of Origin: Hebei, China (Mainland)

    • Transportation: Ocean,Land

    CNC pipe intersecting line cutting machine Pipe intersecting line cutting machine is a formed cutting equipment used for fully automatic incising intersecting lines with slope on pipes and cutting pipe end for example one time molding cutting intersecting lines or opening holes on bearing steel pipes and gas and...

China Cutting Robot Suppliers

The Cutting Robot system is made up of industrial robot, robot controller, teaching device, cutting power supply and fixture. Cutting robots are capable of cutting lines, curves, and grooves in different sizes and thicknesses. The system has the characteristics of high work efficiency, simple structure, good repeatability and high reliability.

Curved Plate Bevel Cutting Robot

Scope of application

This equipment is suitable for the measurement,scribing,second precise cutting and variable angle double-sided groove cutting of the thick walled pressure vessels of ellipsoidal head plate, spherical tank ball and other types. It`s suitable for quick, batch, high precision cutting of the large scale curved plate. This product is successfully applied to the measurement, scribing and high precision bevel cutting of CV large elliptical head plate in the Chinese third generation nuclear power technology-AP1000

Performance characteristics

• It can noncontactly measure of curved plate pressing precision without measurement templet and generate report automatically.

• It can automatically generate optimal cutting path according to the measured data and precisely scribe without scribing templet.

•It can automatically cut the bevel of the curved plate without laying the track and track the thermal deformation of the curved plate cutting. It has the feature of high cutting precision.

• Ensure the arc length precision of each steel plate, thus ensuring the interchangeability of steel plate. The quality of the cutting surface is high, thereby reducing the grinding and welding defects

• It can automatically complete the whole process of the measuring, scribing and cutting with the six axises linkage.It reduces the requirements of the worker`s operation skills.

• Curved plate don`t need strict orientation.

Technical parameters

Type

MPCR-5D6000

Host structure

Gantry,bilateral drive,Cartesian coordinates (XYZ) + the axis of rotation (UV)

Machine size

18000mm×6000mm×4500mm

Gauge (Center)

6000mm

Range

Of

running

effective cutting length (X axis)

12500mm

accuracy

X axis ±0.5mm

effective cutting length (Y axis)

4500mm

Y axis ±0.5mm

effective cutting length (Z axis)

1500mm

Z axis ±0.2mm

The rotation range of U axis (horizontal axis)

360° infinite rotate

U axis (horizontal axis) ±10′

The range of V axis (angle of cutting gun)

±135°(angle between V axis and the plumb line)

V axis (angle of cutting gun)

±10′

The range of V axis (the spin axis of double-cutting gun)

±90°

W axis ±10′
